The device has a 2T2R ac Wi-Fi module. It offers up to 100 Mbps in 2.4 GHz mode and up to 550 Mbps in 5 GHz mode.2 The device also has a built-in 100 Mbps Ethernet port.
Dimensions
| Width/depth/height, mm | 115x115x28 |
| Weight, g | 170 |
Hardware
| Chipset | Amlogic S905X2 |
| Processor | Quad-core ARM Cortex-A53, 1,900 MHz |
| Performance | 18,400 DMIPS |
| RAM | 1 GB DDR3 |
| Flash memory | 4 GB eMMC |
Software
| Operating system | Linux 4.9 |
| DRM option | Upon request |
| Middleware supported | Pre-integrated Ministra TV platform. Image enhancement with operator’s applications, customization, or full replacement available |
Interfaces
| HDMI 2.1, 100 Mbps Ethernet, USB 3.0 × 1, USB 2.0 × 1, built-in 2T2R ac Wi-Fi module |
Sources of media content
| PC or NAS, multimedia broadcasts (RTSP, RTP, UDP, IGMP, HTTP), USB devices |
Audio & video
| Audio сodecs | MPEG L1/L2/L3, AAC-LC, HE AAC V1/V2, APE, FLAC, Dolby Digital Plus™ |
| Video modes | 2160p, 1080i, 1080p, 720p, 576p, NTSC, PAL |
| Video сodecs | H.265/HEVC (optional), H.264 (AVC), MPEG-1/2, MPEG-4, XviD, 3D video support |
| Video containers | TS, MTS, AVI, MPEG, MP4, MOV, MKV, M2TS, VOB, 3GP |
| Image formats | JPEG, PNG, BMP, RAW |
| Subtitles | DVB, PGS, SRT, SSA/ASS, SUB, Teletext, WebVtt, closed captioning |
| Playlist formats | M3U, M3U8, PLS, CUE |
